BayoWrap Roof 05 Flame Spec Underlay

$0.00

Bayonet’s BayoWrap Roof 05 Flame Spec Underlay is a medium weight synthetic building underlay for use under roof claddings.

Bayonet Bayowrap Roof 05 Flame Spec Underlay is a high quality functional film covered with two layers of durable non-woven spun-bonded polypropylene fabric providing a fire retardant self-supporting 3 layer roof underlay. This is the perfect economical option where a fire retardant underlay is required.

Features

Durable

  • Stronger & more resistant to shrinkage than conventional kraft underlays.

Breathable

  • Very high vapour permeability.

Efficient

  • Spans up to 1200mm centres without support on 3 degrees and above. (When laid horizontally)

  • Preprinted with 150mm overlap laying lines.

  • 3000mm wide roll providing an additional 6% coverage due to less overlaps.

Compliant

  • BRANZ Appraised

  • CodeMark Certified

Bayonet’s BayoWrap Roof 05 Flame Spec Underlay is a medium weight synthetic building underlay for use under roof claddings.

Bayonet Bayowrap Roof 05 Flame Spec Underlay is a high quality functional film covered with two layers of durable non-woven spun-bonded polypropylene fabric providing a fire retardant self-supporting 3 layer roof underlay. This is the perfect economical option where a fire retardant underlay is required.

Features

Durable

  • Stronger & more resistant to shrinkage than conventional kraft underlays.

Breathable

  • Very high vapour permeability.

Efficient

  • Spans up to 1200mm centres without support on 3 degrees and above. (When laid horizontally)

  • Preprinted with 150mm overlap laying lines.

  • 3000mm wide roll providing an additional 6% coverage due to less overlaps.

Compliant

  • BRANZ Appraised

  • CodeMark Certified

Applications

  • A synthetic wall underlay for use under all wall claddings

Specifications

  • UV Exposure: 90 days allowed exposed to UV prior to cladding

  • Self Supporting: can be laid down to 3 degrees for horizontal laying, or down to 10 degrees for vertical laying

  • Edge tear (average): Machine direction = 192 N, Cross direction = 106 N

  • Tensile strength (average): Machine direction = 3.84 kN/m, Cross direction - 2.05 kN/m

  • Fire Retardant: Flammability index ≤5

  • Water Resistant: ≥100mm

  • Vapour Permeable: ≤7MN s/g

  • Absorbent: ≥150 g/m²

Roof layout

Specifications

Sizes

Choose from the following options.

BayoWrap Roof 05 Flame Spec Underlay
SKU Roll Width (mm) Roll Length (Lineal M) Total Area (m²) Weight (kg)
FSHW300010030003410011.2
FSHW150050150034505.6
FSHW135075135056758.5
