Permanent Wire Strainers

$0.00

Permanent wire straining for rural fencing

  • Designed for NZ fencing tools and wire systems

  • Tested to full wire tension with no gear or frame failure

Materials / durability

  • Cast Aluminium alloy gear wheel for strength and durability

  • Zinc-Aluminium-Magnesium coated steel frame for advanced corrosion protection

  • Galvanised or zinc-plated spring steel clip

Features

  • Secure spring locking clip for safe lock-off under tension

  • Compatible with NZ-standard ratchet tensioner bars

  • Designed for high-tensile fencing wire

  • Galvanised steel wing plates (2.0 mm minimum thickness)

  • Galvanised spring locking clip

  • Designed so wire will fail before the strainer

  • Gear slot sized for NZ-standard 5 mm square tensioner bar

  • Built for long-term outdoor use in high-tension fencing.

Permanent wire straining for rural fencing

  • Designed for NZ fencing tools and wire systems

  • Tested to full wire tension with no gear or frame failure

Materials / durability

  • Cast Aluminium alloy gear wheel for strength and durability

  • Zinc-Aluminium-Magnesium coated steel frame for advanced corrosion protection

  • Galvanised or zinc-plated spring steel clip

Features

  • Secure spring locking clip for safe lock-off under tension

  • Compatible with NZ-standard ratchet tensioner bars

  • Designed for high-tensile fencing wire

  • Galvanised steel wing plates (2.0 mm minimum thickness)

  • Galvanised spring locking clip

  • Designed so wire will fail before the strainer

  • Gear slot sized for NZ-standard 5 mm square tensioner bar

  • Built for long-term outdoor use in high-tension fencing.

GET EXPERT ADVICE…

From our Customer Support team - then we’ll connect you with a local distributor.

Enquire Now

  • Cast Aluminium alloy gear wheel

  • Zinc-Aluminium-Magnesium coated steel frame

  • Galvanised or zinc-plated spring steel clip

Applications

  • Permanent agricultural fencing using 3.15 mm Zn-Al coated high-tensile wire (1050–1450 MPa)

  • General Purpose

Permanent wire strainer
SKU Wire Diameter Wire Type Pack Quantity
PWSSC253.15mm (16-12 SWG)High Tensile 25
